e-STUDIO2822AM

Why compromise? Now you can have A3 from an A4 footprint.

The ideal A4 model for those who do not want to miss the occasional A3 output, but are pressed for space. Print, scan and copy in A3 with our unique A4 model.
  • The e-STUDIO2802AM has a footprint equivalent to that of an A4 printer, but it is also able to print, scan and copy A3 formats.
  • Via bypass feeding and the Automatic Document Feeder, you can switch effortlessly to the larger format when needed.
  • With a print speed of 28 pagers per minute, its robustness and compact size, it fits into many work environments like start-up enterprises, back offices or even temporarily into warehouses.

Specifications: e-STUDIO2822AM

GENERAL

Print & Copy Speed:
A4: 28 ppm
A3: 14 ppm
Warm-up Time:
~ 18 seconds
Paper Size & Weight:
Cassette: A4, 64-80 g/m2
Bypass: A5R-A3, 52-216 g/m2
Paper Capacity:
Cassette: 1x 250 sheets, Bypass: 1x 50 sheets
Max. 300 sheets
Inner Output Tray:
100-sheet capacity
Automatic Duplex:
A5R-A3, 64-80 g/m2
Memory:
512 MB RAM
Interface:
10Base-T/100Base-TX (incl. IPv6), High Speed USB 2.0, WLAN* (IEEE 802.11 b/g/n)
Dimensions & Weight:
390 x 540 x 505 mm (W x D x H), ~ 26.5 kg
Initial Consumables:
Toner, Drum, Developer

PRINT

Resolution:
Max. 2,400 x 600 dpi, with smoothing
Page Description Language:
PCL 5e and PCL 6 compatible
Supported Systems:
Windows 10/8.1/7/Server 2008 SP2 (32/64 bit), Windows Server 2016/Server 2012/Server 2008 R2 SP1 (64 bit), Mac OS 10.11-10.14, Linux
Print Functions:
A3-printing via Bypass, Universal Printer Driver, Print from USB, Multiple pages per sheet, Toner save mode

SCAN

Resolution:
Max. 600 x 600 dpi
Scan Speed:
Monochrome/Colour: 25/18 ipm (300 dpi)
Document Feeder:
50-sheet capacity, A5R-A3, 50-104 g/m2
Scan Modes:
Colour, Greyscale, Monochrome
File Formats:
JPEG, Multi/Single Page TIFF/PDF (via e-STUDIO Scan Editor)
Scan Functions:
A3-scanning via Automatic Document Feeder, Scan templates, Scan to USB, Scan to E-Mail, TWAIN, Scan to Mobile

COPY

Resolution:
Scan: 600 x 600 dpi
Print: 2,400 x 600 dpi with smoothing
First Print Output Time:
~ 6.4 seconds
Zoom:
Platen: 25-400%, RADF: 25-400%
Copy Modes:
Text, Text/Photo, Photo, Background erase
Copy Functions:
A3-copying via Automatic Document Feeder and Bypass, Copy templates, ID Card Copy, Edge Erase, 2-in-1/4-in-1 mode, Auto sort, Electronic sort

SYSTEM & SECURITY

Device Management:
TopAccess for remote administration and configuration
System Features:
Internal toner recycling, Energy-saving modes
Accounting & Security:
100 department codes, IP and MAC address filter, SSL support

Accessories

Hardware

  • GQ-1131 - Harness Kit for Coin Controller
  • GN-1160 - Wireless LAN Module

Software

Drivers & Updates

more ...
